1800 LB.. PULL LINE.3000.DETECTABLE.UNPRINTED…….
Sold in increments of 3,000′ and 5,000′. UOM is feet.
Detectable Pull Tape is used to locate buried conduit and pulling inner duct or cable into existing conduits. Detectable pull tape is made with a copper tracer wire woven into the tape providing a continuous circuit and is available in 1250#, 1800# and 2500# tensile strenghts in continuous lengths.
ETCO FINGER CAPS
| PART # | SIZE | CABLE | # OF FINGERS | BOX QTY | WEIGHT PER BOX (lbs.) |
|---|---|---|---|---|---|
| CA-075 | 3/4" | .500" | 1 | 100 | 4 |
| CA-100 | 1" | .500" | 1 | 100 | 4 |
| CA-125 | 1-1/4" | .750" – .500" | 1-STEPPED | 100 | 6 |
| CA-150 | 1-1/2" | 1.000" – .500" | 1-STEPPED | 100 | 7 |
| CA-200 | 2" | 1.000" – .500" | 1-STEPPED | 100 | 7 |
| CA-200-3 | 2" | .750" OR .875" COAX | 3 | 100 | 7 |
| CA-287 | 2-1/2" |
1.300" – 1.050" .750" – .450" |
1-STEPPED | 100 | 9 |
| CA-287-3 | 2-1/2" |
(2) @ .800" – .600" – .350" (1) @ .625" – .475" – .325" |
3-STEPPED | 100 | 9 |
| CA-350 | 3" |
1.300" – 1.050" .750" – .450" |
1-STEPPED | 100 | 8 |
| CA-350-3 | 3" |
(2) @ .800" – .600" – .350" (1) @ .625" – .475" – .325" |
3-STEPPED | 100 | 13 |
